Manufactured from top quality components, this is your best option and inexpensive replacement for you rebuild, repair, and maintenance needs - an OE replacement product for your damaged or aged factory part.
Feature
100% Brand New
Direct Aftermarket replacement.
Professional installation is recommended.
High quality parts.
Durable and reliable during poor weathers.
REPLACES:
Bendix: K129605, K067114
Haldex: GC3030CW, GC3030S4CW
Other: BTS-3030-WCR, GTA-3030-WCR
SPECIFICATIONS:
Actuator Type Size: 3030
Stroke Type: Standard
Available Stroke: 2-1/2", 64mm
Length from mounting bracket to end of Spring Housing: 9", 229mm
Length of Piggyback: 6-13/16", 173mm
Dimension at rolled Spring Housing flange: 8-5/16", 211mm
Dimension at Service Clampband: 10-3/16", 259mm
Pushrod Length from face of Service Housing: 1"
Distance to Clevis Pin centerline from face of Service Housing: 2-1/4"
